Jovision
jvs nd6606 hd r2 6ch h 265 1 sata nvr
JVS-ND6606-HD
1 / 1 Tap or click to enlarge
Sold by Maxibern Technologies
Key Features: Support 4K Output Support 128CH 5.0Megapixel IP Cameras 16x SATA, up to 10TB each 2x HDMI, 2x VGA, 2x RJ45 Support Audio Input and Output; Support Alarm Input and Output. 16 In & 4 Out Support RS485 Support dual network port, Network fault tolerance and Load balancing.
Check the camera or recorder technology, power requirements and supported connections for your installation. Recording storage, cables and installation are included only when listed.
| Brand | Jovision |
|---|---|
| Intelligent Analysis | Support Region Intrusion, Line Crossing, Crowd Density, Fast Moving, Scene Change, People Counting, Video Tampering, Defocus Detection、Fire Detection、Leftover Picking、Sound Detection |
| Alarm Method | Email Alarm, External Alarm |
| Ethernet | 100/1000Mbps Adaptive |
| Power Supply | 100-240V/6-3A/60-50HZ |
| Working Temperature | -10°C ~ 55°C |
| Working Humidity | 10% ~ 90% |
| Smart Phone | iPhone, Android |
| Consumption | ≤ 10 W (Without HDD) |
| Dimensions | 530x144x483(mm) |
| Weight | ≤ 6.2Kg (Without HDD) |
| Two-Way Talk | Support |
| IP Camera Input | 128 Channel |
| Multi-screen Display | 1/ 4/ 5/ 6 up to 64 x 2 |
| Compression | H.265/ H.264 |
| Sync Playback | 9CH 5.0MP (20fps)/ 11CH 4.0MP/ 13CH 3.0MP/16CH 2.0MP |
| Search Mode | Channel Number/ Recording Type/ Date |
| Backup Mode | Support USB/ Portable HDD FAT32/ NTFS/ exFAT |
| Network Function | TCP/IP, UDP/IP, CloudSEE, SMTP, NTP, DHCP |
| Interoperability | ONVIF Standard, CloudSEE 2.0 |
| SATA | 16 x SATA Interface |
| Capacity | Up to 10TB Max. |
| Video Output | HDMI:4K@60Hz/ 4K@30Hz/ 2K@60Hz/ 2K@30Hz/ 1920x1080/ 1440x900/ 1280x1024/ 1280x720/ 1024x768; VGA: 1920x1080/ 1440x900/ 1280x1024/ 1280x720/ 1024x768 |
| Audio In & Out | Support |
| Video Access | 128CH 5.0MP |
| File Format | Log: *.txt/ Picture: *.JPG/ Video: *.mp4 |
| Video Playback | Auto/ Timing/ Alarm/ Motion Detection/ Intelligent Analysis |
| Max. Remote Channels | 128 LAN/ 64 WAN |
| Network Interface | 2x RJ45 |
| USB Interface | 2x USB2.0, 1xUSB3.0 |
| PTZ Interface | RS485 |
| Controlling Device | Mouse / Front panel |
| Alarm Input | 16CH |
| Alarm Output | 4CH |
| Digital Zoom | Support |
| Alarm Snapshot | Support |
